Holographic Weapon Sights

Holographic Weapon Sights

The Holographic Weapon Sight is a revolutionary technology.  These sights maximize the operator's peripheral vision, which guarantees faster target acquisition and gives the operator greater control in the engagement zone.  The features built into EOTech holographic weapon sights provide a number of advantages:

  • Maximum situational awareness from true heads-up display and two eyes open shooting
  • Variety of reticle patterns to meet your shooting needs with the smallest, most precise dot in the industry
  • Rugged reliability and undetectable operation in any environment
  • Adjustable reticle brightness settings for many situations

Learn More...

View General Specifications

General Specifications

The following general specifications apply to most EOTech holographic weapon sights models.


  • Optics: Holography
  • Magnification: 1x
  • Eye Relief: Unlimited
  • Sealing: Internally fog-resistant optics
  • Adjustment (per click): Approx 0.5 MOA (1/2" at 100 yds) when zeroing
  • Adjustment Range: +/-40 MOA travel

Heads-Up-Display Window

  • Optical Surfaces: Anti-reflective coating on external surfaces
  • Window Dimensions: 1.20" x 0.85" (30 x 23 mm)
  • Front Window Material: ⅛" solid glass
  • Rear Window Material: 3/16" thick laminate
  • Field of View (100 yds): 30 yds (28 m) at a 3" eye relief


  • Brightness Settings:
    • 20 daylight settings
    • 10 additional settings on night vision-compatible models
    • Scrolling feature
    • Adjustable for visibility in the brightest sunlight
    • Compatible with Gen I through III night vision devices
  • Auto Battery Check Indicator: Reticle flashes on startup when battery is low
  • Auto Shutdown: User-controlled; shuts down at 4 or 8 hours


  • EOTech reserves the right to change the product specifications at any time.
  • All EOTech material is for information purposes only and does not constitute any binding obligation or agreement by EOTech; and all claims about performance and performance characteristics assume normal, responsible usage within the warranty period.
  • EOTech users will often experience a point of impact shift away from the point of aim when the sight is used at a temperature different from the temperature at which the sight was zeroed. The point of aim shift may be greater the more extreme the temperature change. To achieve optimum accuracy, the sight should be re-zeroed whenever the temperature changes from the temperature at which the sight was zeroed.
  • All EOTech sights exhibit a varying degree of parallax depending on operating conditions.
